UHMWPE Sheet Manufacturer | PE1000 Polyethylene Sheet Factory
We are a professional UHMWPE sheet manufacturer supplying PE1000 ultra high molecular weight polyethylene sheets for industrial applications worldwide. With stable quality, competitive pricing, and custom machining services, our UHMWPE sheets are trusted by customers in more than 30 countries.
Key Features of UHMWPE (PE1000) Sheet
Ultra high molecular weight (3–9.2 million g/mol)
Excellent wear and abrasion resistance
Low friction coefficient and self-lubricating surface
High impact strength, even at low temperatures
Chemical and corrosion resistance
- Non-toxic and food-grade options available
Ordering Information
Ultra-high molecular weight polyethylene sheets are made from high-quality polymer materials and pro-
cessed using compression molding.
size
We can also cut them to size within this range for sale.
| Size(mm) | Thickness(mm) | Color |
| 1220*2440 |
10-110 |
black/ white/yellow/ |
| 1250*3050 | ||
| 1010*4080 | ||
| 1550*4100 | ||
| 1290*4080 | ||
| 2050*4100 | ||
| 1540*6080 | ||
| 1260*6180 | ||
| 1550*6180 | ||
| 1630*6130 | ||
| 1320*6200 |
Color
It can add dyes as required to customize boards of different colors. Common colors are black, white, yellow,
green, blue, red, and purple.
Thickness
The thickness available for compression molding ranges from 10mm to 200mm, and can be customized according
to specific requirements.Common thickness options include 10mm, 15mm,20mm,25mm, 30mm,35mm,
40mm, 50mm,70mm,80mm,100mm,and 110mm.
Molecular Weight
The molecular weights available are 3.5 million, 5 million,7.2 million,and 9.2 million.
| data sheet | |||
| Test Items | Test method | Unit | Value |
| General properties | DIN 53479 | g/cm3 | 0.934 |
| Molecular weight | 106g/mol | 4.5 | |
| Elongation at break | IS0 527 | % | >340 |
| Tensile modulus | IS0527 | Mpa | 1200 |
| Yield stress | IS0 527 | Mpa | 27 |
| Hardness | IS0 868 | Shore D | 67 |
| Melting temperature | DIN53736 | 0C | 135 |
| Water absorption | 24h/RT | % | <0.01 |
| Friction coefficient | 0.01-0.03 | ||
Characteristics of uhmwpe sheets
High wear resistance: UHMWPE has the best wear resistance among plastics, improving with higher molecular
weight of polyethylene.
High impact resistance: lmpact strength of UHMWPE correlates with its molecular weight, peaking around 2 mil-
lion and potentially decreasing with higher weights.
Low friction coefficient: UHMWPE has very low friction and excellent self-lubricating properties, ideal for bear-
ings and liners.
Excellent chemical resistance: Resistant to most acids,alkalis, water, and detergents, except concentrated nitric
and sulfuric acids.
Low water absorption: UHMWPE absorbs minimal water,swelling less than nylon.
Good thermal properties: Heat distortion temperature is 85°C, usable up to 90°C under lighter loads, and remains
ductile down to -269°C.
Excellent electrical properties: Maintains high electrical resistivity and breakdown voltage over wide tempera-
ture and frequency ranges.
Non-toxic: Odorless, tasteless, and safe for food and drug contact according to FDA and USDA standards.
Applications of UHMWPE Sheets
Industrial Manufacturing:
Conveyor Systems: Reduces energy loss and maintenance costs with low friction and high wear resistance.
Mechanical Parts: Provides durability in gears,bearings, and washers for high-load machinery.
Food Processing Equipment: Ensures hygiene in scrapers and guides due to chemical stability.
Medical Devices:
Artificial Joints: Offers biocompatibility and durability in hip and knee replacements.
Surgical Instruments: Used for lightweight and versatile surgical tools and supports.
Sports Equipment:
Skis and Skateboards: Provides durability and smooth glide for ski and skateboard surfaces.
Ice Sports Equipment: ldeal for ice skates and curling stones due to low friction and wear resistance.
Protective Materials:
Ballistic Protection: High-strength material for ballistic vests and protective plates.
Marine Applications:Absorbs impact in ship and dock fenders, extending their lifespan.
Environmental and Special Applications:
Sliding Doors and Windows: Ensures smooth operation in sliding door and window tracks.
Agricultural Machinery:Resists abrasion in components for seeding and harvesting machines.
Pre-Purchase Notice
Product prices do not include shipping costs. Please consult customer service for specific shipping fees.
Shipping costs vary based on quantity, delivery address,and shipping timeframe. We will select the most cost-ef-
fective option according to your specific circumstances to minimize your shopping costs.
As a direct UHMWPE sheet factory, we offer fast delivery, OEM service, and bulk supply solutions.
Contact us today for a competitive UHMWPE sheet price.
